| Size | : 14x6.5, 15x10, 15x7, 15x8 |
| Finish | : Machined, Polished |
|
|
| PART # | SIZE | FINISH | PATTERN | OFFSET | BSM | CAP # | LOAD | SHIP WT. |
 |
||||||||
 0280-4605 |
14x6.5 | Machined | 4 on 4.25/4.5 | -6 mm | 3 7/16 | 3121-00 | 1580 lbs. | 19 lbs. |
| 0280-4606 |
14x6.5 | Machined | 5 on 4.5/4.75 | -6 mm | 3 7/16 | 3121-00 | 1580 lbs. | 19 lbs. |
| 0280-4666 |
14x6.5 | Machined | 6 on 5.5 | -6 mm | 3 7/16 | 3121-00 | 1580 lbs. | 19 lbs. |
| 0280-5005 |
15x10 | Machined | 4 on 4.25/4.5 | -45 mm | 3 11/16 | 3121-00 | 1580 lbs. | 27 lbs. |
| 0280-5006 |
15x10 | Machined | 5 on 4.5/4.75 | -45 mm | 3 11/16 | 3121-00 | 1580 lbs. | 27 lbs. |
| 0280-5055 |
15x10 | Machined | 5 on 5/5.5 | -45 mm | 3 11/16 | 3121-00 | 1580 lbs. | 27 lbs. |
| 0280-5066 |
15x10 | Machined | 6 on 5.5 | -45 mm | 3 11/16 | 3121-00 | 1580 lbs. | 27 lbs. |
| 0280-5705 |
15x7 | Machined | 4 on 4.25/4.5 | 0 mm | 4 | 3121-00 | 1580 lbs. | 20 lbs. |
| 0280-5706 |
15x7 | Machined | 5 on 4.5/4.75 | 0 mm | 4 | 3121-00 | 1580 lbs. | 20 lbs. |
| 0280-5755 |
15x7 | Machined | 5 on 5/5.5 | 0 mm | 4 | 3121-00 | 1580 lbs. | 20 lbs. |
| 0280-5766 |
15x7 | Machined | 6 on 5.5 | 0 mm | 4 | 3121-00 | 1580 lbs. | 20 lbs. |
| 0280-5805 |
15x8 | Machined | 4 on 4.25/4.5 | -30 mm | 3 1/4 | 3121-00 | 1580 lbs. | 24 lbs. |
| 0280-5806 |
15x8 | Machined | 5 on 4.5/4.75 | -30 mm | 3 1/4 | 3121-00 | 1580 lbs. | 24 lbs. |
| 0280-5855 |
15x8 | Machined | 5 on 5/5.5 | -30 mm | 3 1/4 | 3121-00 | 1580 lbs. | 24 lbs. |
| 0280-5866 |
15x8 | Machined | 6 on 5.5 | -30 mm | 3 1/4 | 3121-00 | 1580 lbs. | 24 lbs. |
| 0289-4605 |
14x6.5 | Polished | 4 on 4.25/4.5 | -6 mm | 3 7/16 | 3121-09 | 1580 lbs. | 19 lbs. |
| 0289-4606 |
14x6.5 | Polished | 5 on 4.5/4.75 | -6 mm | 3 7/16 | 3121-09 | 1580 lbs. | 19 lbs. |
| 0289-4666 |
14x6.5 | Polished | 6 on 5.5 | -6 mm | 3 7/16 | 3121-09 | 1580 lbs. | 19 lbs. |
| 0289-5005 |
15x10 | Polished | 4 on 4.25/4.5 | -45 mm | 3 11/16 | 3121-09 | 1580 lbs. | 27 lbs. |
| 0289-5006 |
15x10 | Polished | 5 on 4.5/4.75 | -45 mm | 3 11/16 | 3121-09 | 1580 lbs. | 27 lbs. |
| 0289-5055 |
15x10 | Polished | 5 on 5/5.5 | -45 mm | 3 11/16 | 3121-09 | 1580 lbs. | 27 lbs. |
| 0289-5066 |
15x10 | Polished | 6 on 5.5 | -45 mm | 3 11/16 | 3121-09 | 1580 lbs. | 27 lbs. |
| 0289-5705 |
15x7 | Polished | 4 on 4.25/4.5 | 0 mm | 4 | 3121-09 | 1580 lbs. | 20 lbs. |
| 0289-5706 |
15x7 | Polished | 5 on 4.5/4.75 | 0 mm | 4 | 3121-09 | 1580 lbs. | 20 lbs. |
| 0289-5755 |
15x7 | Polished | 5 on 5/5.5 | 0 mm | 4 | 3121-09 | 1580 lbs. | 20 lbs. |
| 0289-5766 |
15x7 | Polished | 6 on 5.5 | 0 mm | 4 | 3121-09 | 1580 lbs. | 20 lbs. |
| 0289-5805 |
15x8 | Polished | 4 on 4.25/4.5 | -30 mm | 3 1/4 | 3121-09 | 1580 lbs. | 24 lbs. |
| 0289-5806 |
15x8 | Polished | 5 on 4.5/4.75 | -30 mm | 3 1/4 | 3121-09 | 1580 lbs. | 24 lbs. |
| 0289-5855 |
15x8 | Polished | 5 on 5/5.5 | -30 mm | 3 1/4 | 3121-09 | 1580 lbs. | 24 lbs. |
| 0289-5866 |
15x8 | Polished | 6 on 5.5 | -30 mm | 3 1/4 | 3121-09 | 1580 lbs. | 24 lbs. |
