| Size | : 14x6.5, 15x10, 15x7, 15x8, 16.5x8.25, 16x7 |
| Finish | : Machined, Polished |
|
|
| PART # | SIZE | FINISH | PATTERN | OFFSET | BSM | CAP # | LOAD | SHIP WT. |
 |
||||||||
 0550-4612 |
14x6.5 | Machined | 5 on 4.5 | -11 mm | 3 1/4 | 3170-06 | 1580 lbs. | 17 lbs. |
| 0550-4634 |
14x6.5 | Machined | 5 on 4.75 | -11 mm | 3 1/4 | 3170-06 | 1580 lbs. | 17 lbs. |
| 0550-4666 |
14x6.5 | Machined | 6 on 5.5 | -11 mm | 3 1/4 | N/I | 1580 lbs. | 17 lbs. |
| 0550-5012 |
15x10 | Machined | 5 on 4.5 | -50 mm | 3 1/2 | 3170-06 | 2100 lbs. | 23 lbs. |
| 0550-5034 |
15x10 | Machined | 5 on 4.75 | -50 mm | 3 1/2 | 3170-06 | 2100 lbs. | 23 lbs. |
| 0550-5050 |
15x10 | Machined | 5 on 5 | -50 mm | 3 1/2 | 3171-06 | 2100 lbs. | 23 lbs. |
| 0550-5057 |
15x10 | Machined | 5 on 5.5 | -50 mm | 3 1/2 | N/I | 2100 lbs. | 23 lbs. |
| 0550-5066 |
15x10 | Machined | 6 on 5.5 | -50 mm | 3 1/2 | N/I | 2100 lbs. | 23 lbs. |
| 0550-5712 |
15x7 | Machined | 5 on 4.5 | -5 mm | 3 3/4 | 3170-06 | 1900 lbs. | 19 lbs. |
| 0550-5734 |
15x7 | Machined | 5 on 4.75 | -5 mm | 3 3/4 | 3170-06 | 1900 lbs. | 19 lbs. |
| 0550-5750 |
15x7 | Machined | 5 on 5 | -5 mm | 3 3/4 | 3171-06 | 1900 lbs. | 19 lbs. |
| 0550-5757 |
15x7 | Machined | 5 on 5.5 | -5 mm | 3 3/4 | N/I | 1900 lbs. | 19 lbs. |
| 0550-5766 |
15x7 | Machined | 6 on 5.5 | -5 mm | 3 3/4 | N/I | 1900 lbs. | 19 lbs. |
| 0550-5812 |
15x8 | Machined | 5 on 4.5 | -30 mm | 3 1/4 | 3170-06 | 1900 lbs. | 20 lbs. |
| 0550-5834 |
15x8 | Machined | 5 on 4.75 | -30 mm | 3 1/4 | 3170-06 | 1900 lbs. | 20 lbs. |
| 0550-5850 |
15x8 | Machined | 5 on 5 | -30 mm | 3 1/4 | 3171-06 | 1900 lbs. | 20 lbs. |
| 0550-5857 |
15x8 | Machined | 5 on 5.5 | -30 mm | 3 1/4 | N/I | 1900 lbs. | 20 lbs. |
| 0550-5866 |
15x8 | Machined | 6 on 5.5 | -30 mm | 3 1/4 | N/I | 1900 lbs. | 20 lbs. |
| 0550-6888 |
16.5x8.25 | Machined | 8 on 6.5 | 0 mm | 4 3/4 | N/I | 3420 lbs. | 28 lbs. |
| 0550-7757 |
16x7 | Machined | 5 on 5.5 | -10 mm | 3 9/16 | N/I | 2500 lbs. | 21 lbs. |
| 0550-7766 |
16x7 | Machined | 6 on 5.5 | -10 mm | 3 9/16 | N/I | 3040 lbs. | 21 lbs. |
| 0550-7787 |
16x7 | Machined | 8 on 170mm | -10 mm | 3 9/16 | N/I | 3420 lbs. | 21 lbs. |
| 0550-7788 |
16x7 | Machined | 8 on 6.5 | -10 mm | 3 9/16 | N/I | 3420 lbs. | 21 lbs. |
| 0559-4612 |
14x6.5 | Polished | 5 on 4.5 | -11 mm | 3 1/4 | 3170-06 | 1580 lbs. | 17 lbs. |
| 0559-4634 |
14x6.5 | Polished | 5 on 4.75 | -11 mm | 3 1/4 | 3170-06 | 1580 lbs. | 17 lbs. |
| 0559-4666 |
14x6.5 | Polished | 6 on 5.5 | -11 mm | 3 1/4 | N/I | 1580 lbs. | 17 lbs. |
| 0559-5012 |
15x10 | Polished | 5 on 4.5 | -50 mm | 3 1/2 | 3170-06 | 2100 lbs. | 23 lbs. |
| 0559-5034 |
15x10 | Polished | 5 on 4.75 | -50 mm | 3 1/2 | 3170-06 | 2100 lbs. | 23 lbs. |
| 0559-5050 |
15x10 | Polished | 5 on 5 | -50 mm | 3 1/2 | 3171-06 | 2100 lbs. | 23 lbs. |
| 0559-5057 |
15x10 | Polished | 5 on 5.5 | -50 mm | 3 1/2 | N/I | 2100 lbs. | 23 lbs. |
| 0559-5066 |
15x10 | Polished | 6 on 5.5 | -50 mm | 3 1/2 | N/I | 2100 lbs. | 23 lbs. |
| 0559-5712 |
15x7 | Polished | 5 on 4.5 | -5 mm | 3 3/4 | 3170-06 | 1900 lbs. | 19 lbs. |
| 0559-5734 |
15x7 | Polished | 5 on 4.75 | -5 mm | 3 3/4 | 3170-06 | 1900 lbs. | 19 lbs. |
| 0559-5750 |
15x7 | Polished | 5 on 5 | -5 mm | 3 3/4 | 3171-06 | 1900 lbs. | 19 lbs. |
| 0559-5757 |
15x7 | Polished | 5 on 5.5 | -5 mm | 3 3/4 | N/I | 1900 lbs. | 19 lbs. |
| 0559-5766 |
15x7 | Polished | 6 on 5.5 | -5 mm | 3 3/4 | N/I | 1900 lbs. | 19 lbs. |
| 0559-5812 |
15x8 | Polished | 5 on 4.5 | -30 mm | 3 1/4 | 3170-06 | 1900 lbs. | 20 lbs. |
| 0559-5834 |
15x8 | Polished | 5 on 4.75 | -30 mm | 3 1/4 | 3170-06 | 1900 lbs. | 20 lbs. |
| 0559-5850 |
15x8 | Polished | 5 on 5 | -30 mm | 3 1/4 | 3171-06 | 1900 lbs. | 20 lbs. |
| 0559-5857 |
15x8 | Polished | 5 on 5.5 | -30 mm | 3 1/4 | N/I | 1900 lbs. | 20 lbs. |
| 0559-5866 |
15x8 | Polished | 6 on 5.5 | -30 mm | 3 1/4 | N/I | 1900 lbs. | 20 lbs. |
| 0559-6888 |
16.5x8.25 | Polished | 8 on 6.5 | 0 mm | 4 3/4 | N/I | 3420 lbs. | 28 lbs. |
| 0559-7757 |
16x7 | Polished | 5 on 5.5 | -10 mm | 3 9/16 | N/I | 2500 lbs. | 21 lbs. |
| 0559-7766 |
16x7 | Polished | 6 on 5.5 | -10 mm | 3 9/16 | N/I | 3040 lbs. | 21 lbs. |
| 0559-7787 |
16x7 | Polished | 8 on 170mm | -10 mm | 3 9/16 | N/I | 3420 lbs. | 21 lbs. |
| 0559-7788 |
16x7 | Polished | 8 on 6.5 | -10 mm | 3 9/16 | N/I | 3420 lbs. | 21 lbs. |
