| Size | : 14x6.5, 15x10, 15x12, 15x7, 15x8, 16.5x12, 16.5x8.25, 16.5x9.75, 16x10, 16x7, 16x8, 17x10, 17x8 |
| Finish | : Polished |
|
|
| PART # | SIZE | FINISH | PATTERN | OFFSET | BSM | CAP # | LOAD | SHIP WT. |
 |
||||||||
 0589-4612 |
14x6.5 | Polished | 5 on 4.5 | -6 mm | 3 7/16 | 3170-06 | 1400 lbs. | 21 lbs. |
| 0589-4634 |
14x6.5 | Polished | 5 on 4.75 | -6 mm | 3 7/16 | 3170-06 | 1400 lbs. | 21 lbs. |
| 0589-4666 |
14x6.5 | Polished | 6 on 5.5 | -6 mm | 3 7/16 | N/I | 1400 lbs. | 21 lbs. |
| 0589-5012 |
15x10 | Polished | 5 on 4.5 | -46 mm | 3 5/8 | 3170-06 | 2500 lbs. | 24 lbs. |
| 0589-5034 |
15x10 | Polished | 5 on 4.75 | -46 mm | 3 5/8 | 3170-06 | 2500 lbs. | 24 lbs. |
| 0589-5050 |
15x10 | Polished | 5 on 5 | -46 mm | 3 5/8 | 3171-06 | 2500 lbs. | 24 lbs. |
| 0589-5057 |
15x10 | Polished | 5 on 5.5 | -46 mm | 3 5/8 | N/I | 2500 lbs. | 24 lbs. |
| 0589-5064 |
15x10 | Polished | 6 on 4.5 | -46 mm | 3 5/8 | 3170-06 | 2500 lbs. | 24 lbs. |
| 0589-5066 |
15x10 | Polished | 6 on 5.5 | -46 mm | 3 5/8 | N/I | 2500 lbs. | 24 lbs. |
| 0589-5212 |
15x12 | Polished | 5 on 4.5 | -72 mm | 3 5/8 | 3170-06 | 2500 lbs. | 24 lbs. |
| 0589-5234 |
15x12 | Polished | 5 on 4.75 | -72 mm | 3 5/8 | 3170-06 | 2500 lbs. | 25 lbs. |
| 0589-5250 |
15x12 | Polished | 5 on 5 | -72 mm | 3 5/8 | 3171-06 | 2500 lbs. | 25 lbs. |
| 0589-5257 |
15x12 | Polished | 5 on 5.5 | -72 mm | 3 5/8 | N/I | 2500 lbs. | 25 lbs. |
| 0589-5266 |
15x12 | Polished | 6 on 5.5 | -72 mm | 3 5/8 | N/I | 2500 lbs. | 25 lbs. |
| 0589-5712 |
15x7 | Polished | 5 on 4.5 | 0 mm | 4 | 3170-06 | 1950 lbs. | 22 lbs. |
| 0589-5734 |
15x7 | Polished | 5 on 4.75 | 0 mm | 4 | 3170-06 | 1950 lbs. | 22 lbs. |
| 0589-5750 |
15x7 | Polished | 5 on 5 | 0 mm | 4 | 3171-06 | 1950 lbs. | 22 lbs. |
| 0589-5757 |
15x7 | Polished | 5 on 5.5 | 0 mm | 4 | N/I | 1950 lbs. | 22 lbs. |
| 0589-5764 |
15x7 | Polished | 6 on 5.5 | 0 mm | 4 | 3170-06 | 1950 lbs. | 22 lbs. |
| 0589-5766 |
15x7 | Polished | 6 on 5.5 | 0 mm | 4 | N/I | 1950 lbs. | 22 lbs. |
| 0589-5812 |
15x8 | Polished | 5 on 4.5 | -30 mm | 3 1/4 | 3170-06 | 2500 lbs. | 22 lbs. |
| 0589-5834 |
15x8 | Polished | 5 on 4.75 | -30 mm | 3 1/4 | 3171-06 | 2500 lbs. | 23 lbs. |
| 0589-5850 |
15x8 | Polished | 5 on 5 | -30 mm | 3 1/4 | 3171-06 | 2500 lbs. | 23 lbs. |
| 0589-5857 |
15x8 | Polished | 5 on 5.5 | -30 mm | 3 1/4 | N/I | 2500 lbs. | 23 lbs. |
| 0589-5864 |
15x8 | Polished | 6 on 4.5 | -30 mm | 3 1/4 | 3170-06 | 2500 lbs. | 23 lbs. |
| 0589-5866 |
15x8 | Polished | 6 on 5.5 | -30 mm | 3 1/4 | N/I | 2500 lbs. | 23 lbs. |
| 0589-6287 |
16.5x12 | Polished | 8 on 170 | -51 mm | 4 5/8 | N/I | 3420 lbs. | 31 lbs. |
| 0589-6288 |
16.5x12 | Polished | 8 on 6.5 | -51 mm | 4 5/8 | N/I | 3420 lbs. | 31 lbs. |
| 0589-6857 |
16.5x8.25 | Polished | 5 on 5.5 | 0 mm | 4 3/4 | N/I | 2100 lbs. | 28 lbs. |
| 0589-6859 |
16.5x8.25 | Polished | 5 on 135 | 0 mm | 4 3/4 | 3171-06 | 2100 lbs. | 28 lbs. |
| 0589-6866 |
16.5x8.25 | Polished | 6 on 5.5 | 0 mm | 4 3/4 | N/I | 2100 lbs. | 28 lbs. |
| 0589-6887 |
16.5x8.25 | Polished | 8 on 170 | 0 mm | 4 3/4 | N/I | 3420 lbs. | 28 lbs. |
| 0589-6888 |
16.5x8.25 | Polished | 8 on 6.5 | 0 mm | 4 3/4 | N/I | 3420 lbs. | 28 lbs. |
| 0589-6959 |
16.5x9.75 | Polished | 5 on 135mm | -18 mm | 4 3/4 | 3169-06 | 2100 lbs. | 29 lbs. |
| 0589-6966 |
16.5x9.75 | Polished | 6 on 5.5 | -18 mm | 4 3/4 | N/I | 2100 lbs. | 29 lbs. |
| 0589-6987 |
16.5x9.75 | Polished | 8 on 170mm | -18 mm | 4 3/4 | N/I | 3420 lbs. | 29 lbs. |
| 0589-6988 |
16.5x9.75 | Polished | 8 on 6.5 | -18 mm | 4 3/4 | N/I | 3700 lbs. | 29 lbs. |
| 0589-7050 |
16x10 | Polished | 5 on 5 | -24 mm | 4 1/2 | 3171-06 | 2100 lbs. | 24 lbs. |
| 0589-7057 |
16x10 | Polished | 5 on 5.5 | -24 mm | 4 1/2 | N/I | 2100 lbs. | 24 lbs. |
| 0589-7059 |
16x10 | Polished | 5 on 135 | -24 mm | 4 1/2 | 3171-06 | 2100 lbs. | 24 lbs. |
| 0589-7066 |
16x10 | Polished | 6 on 5.5 | -24 mm | 4 1/2 | N/I | 2100 lbs. | 24 lbs. |
| 0589-7087 |
16x10 | Polished | 8 on 170 | -24 mm | 4 1/2 | N/I | 3420 lbs. | 24 lbs. |
| 0589-7088 |
16x10 | Polished | 8 on 6.5 | -24 mm | 4 1/2 | N/I | 3420 lbs. | 24 lbs. |
| 0589-7757 |
16x7 | Polished | 5 on 5.5 | +8 mm | 4 1/4 | N/I | 3040 lbs. | 21 lbs. |
| 0589-7766 |
16x7 | Polished | 6 on 5.5 | +8 mm | 4 1/4 | N/I | 3040 lbs. | 21 lbs. |
| 0589-7788 |
16x7 | Polished | 8 on 6.5 | +8 mm | 4 1/4 | N/I | 3040 lbs. | 21 lbs. |
| 0589-7857 |
16x8 | Polished | 5 on 5.5 | -11 mm | 4 | N/I | 2100 lbs. | 24 lbs. |
| 0589-7859 |
16x8 | Polished | 5 on 135mm | -17 mm | 3 3/4 | 3169-06 | 2100 lbs. | 24 lbs. |
| 0589-7866 |
16x8 | Polished | 6 on 5.5 | -11 mm | 4 | N/I | 2100 lbs. | 24 lbs. |
| 0589-7887 |
16x8 | Polished | 8 on 170 | -11 mm | 4 | N/I | 3420 lbs. | 24 lbs. |
| 0589-7888 |
16x8 | Polished | 8 on 6.5 | -11 mm | 4 | N/I | 3420 lbs. | 24 lbs. |
| 0589-8050 |
17x10 | Polished | 5 on 5 | -24 mm | 4 1/2 | 3171-06 | 2100 lbs. | 26 lbs. |
| 0589-8057 |
17x10 | Polished | 5 on 5.5 | -24 mm | 4 1/2 | N/I | 2100 lbs. | 26 lbs. |
| 0589-8059 |
17x10 | Polished | 5 on 135mm | -24 mm | 4 1/2 | 3171-06 | 2100 lbs. | 26 lbs. |
| 0589-8066 |
17x10 | Polished | 6 on 5.5 | -24 mm | 4 1/2 | N/I | 2100 lbs. | 26 lbs. |
| 0589-8087 |
17x10 | Polished | 8 on 170mm | -24 mm | 4 1/2 | N/I | 3420 lbs. | 26 lbs. |
| 0589-8088 |
17x10 | Polished | 8 on 6.5 | -24 mm | 4 1/2 | N/I | 3420 lbs. | 26 lbs. |
| 0589-8857 |
17x8 | Polished | 5 on 5.5 | 0 mm | 4 1/2 | N/I | 2100 lbs. | 25 lbs. |
| 0589-8859 |
17x8 | Polished | 5 on 135 | 0 mm | 4 1/2 | 3171-06 | 2100 lbs. | 25 lbs. |
| 0589-8866 |
17x8 | Polished | 6 on 5.5 | 0 mm | 4 1/2 | N/I | 2100 lbs. | 25 lbs. |
| 0589-8877 |
17x8 | Polished | 7 on 150 | 0 mm | 4 1/2 | N/I | 3040 lbs. | 25 lbs. |
| 0589-8887 |
17x8 | Polished | 8 on 170 | 0 mm | 4 1/2 | N/I | 3420 lbs. | 25 lbs. |
| 0589-8888 |
17x8 | Polished | 8 on 6.5 | 0 mm | 4 1/2 | N/I | 3040 lbs. | 25 lbs. |
| 0589-8894 |
17x8 | Polished | 6 on 135 | 0 mm | 4 1/2 | 3171-06 | 2100 lbs. | 25 lbs. |
